SHELF SUPPORT SINGLE – For shelves up to 7mm (1/4″) thick. (Use with 10mm Rods)

Product Description

Rod Shelf Support Single-Sided — Horizontal Grip-Support / Non-Removable

The RG06-10 rod shelf clamp support features a 16mm (5/8″) diameter round profile fitting, designed for suspending acrylic or glass shelves up to 7mm (1/4″) thick. This high-quality single-sided shelf support is made of solid brass and is compatible with our 10mm rod display system / rod hanging hardware kits.

The side clamps are great for supporting lightweight acrylic shelves, flat tempered glass shelves, and other custom suspended acrylic fixtures. Attaching the clamp supports to shelves is easily done by affixing them onto the shelf edge with the specially designed nylon-tipped grub screw. The entire assembly is then attached to suspended rods and securely locked into the desired position with the set screws and supplied hex key.

Key Features:
• Single-sided shelf-grip clamp support for non-drilled shelves
• Use at least four clamp supports per shelf (longer shelves may require multiple supports fixed to front and back of the shelf)
• Made of solid brass alloy with satin chrome finish
• Clamp supports grip onto shelves up to 7mm (1/4″) thickness
• Recommended Safety Load Limits per Fitting: 12kg (25lb)
• Nylon-tipped grub screws securely fasten the shelves and protect the surfaces from damage
• Works with a wide range of materials, such as acrylic, tempered glass, plywood, aluminum composite, etc.
• Compatible with 10mm (3/8″) diameter rod suspension system

Explore All Mounting Options ❯
